Includes
- Batteries and Charger Sold Separately.
- 1/4in Collet Cone (763637-1)
- Trimmer Base Set (196613-4)
- Straight Guide (122965-7)
- Dust Nozzle Set (195559-1)
- Template Guide 10 (343577-5)
- Trimmer Guide (122703-7)
- Wrench 22 (781011-1)
- Wrench 13 (781039-9)
Features
- Accepts Makita and other industry standard 2 piece template guides
- Brushless (BL) DC motor generates less heat buildup and is ideal for prolonged use in manufacturing and production applications
- Soft start feature gradually increases speed to eliminate start up shock
- Constant speed control maintains constant speed under heavy load
- Variable speed dial allows operator to adjust speed based on materials or application
- Soft brake brings bit to a gentle stop after tool is turned off for maximum operator and material protection
- Anti-restart feature prevents accidental start up of tool during battery changing when switch is locked in the on position
- Flat top design provides a stable platform when changing bits
- Shaft lock button enables quick and easy bit changes and eliminates the need for dual wrenches
- Auto-start Wireless System (AWS) uses Bluetooth technology to communicate between tool and dust extractor to enable wireless on/off control
- Aluminum base and housing offer increased durability and accuracy
- Push button On/Off and Lock/Unlock control
- Trimmer base assembly provides smooth, fast cutting and easy handling
- Optional plunge base assembly (part no. 196094-2) with precision cutting depth adjustment for accurate plunge cutting applications
- Optional offset base assembly (part no. 196093-4) allows operator to make close to wall cuts of just 3/4in
- Optional tilt base (part no. 196092-6) ideal for fast, easy and accurate angled cuts
- Interchangeable bases offer maximum versatility, high bit visibility and non-marring plastic base for smooth movement and protection of materials
- eXtreme Protection Technology (XPT) offers maximum protection and dust, debris and liquids for optimal performance in extreme conditions
Specifications
- Battery Capacities: 40V Max Li-Ion
- Collet Capacity: 1/4in (6.35 mm)
- No Load Speed: 10,000 - 31,000 RPM
- Vibration Level: 2.5 m/s²
- Noise Level: 81 dB(A)
- Overall Height: 7-3/4in (197 mm)
- Net Weight: 3.4 lbs (1.5 kg)
