Gearwrench 1/2" drive sockets are manufactured from alloy steel for maximum durability and strength. Gearwrench's off corner loading design reduces fastener rounding and the chamfered opening help guide the socket on to fasteners. GEARWRENCH's sockets feature a double line (SAE) and knurled (metric) ring help easily identify standard and metric sockets.
Features:
- Off-corner loading design reduces fastener rounding
- Chamfered opening quickly guides fasteners into socket
- Hard stamped size markings
- Double line (SAE) and knurled (metric) ring help easily identify standard and metric sockets
- Bright, full polish chrome finish easily wipes clean and resists corrosion
- Meets or exceeds ASME specifications
- Prop 65: WARNING: This product contains or produces a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
Specifications:
- ASME Specification: B107.5M
- Overall Length: 1.488 in
- Drive Tang Size: 1/2 in
- Knurled: Yes
- Type: Socket
- Packaging: Carded
- Warranty: Full Lifetime
- Length Format: Standard
- Finish: Full Polish Chrome
- Magnetic: No
- SAE/Metric/Torx: Metric
- Drive Type: 6 Point
- Material: Alloy Steel
- Dim. F: Length to Shoulder: 0.748 in
10mm Standard Socket:
- Dim. A: Drive End: 0.866 in
- Dim. B: Wrench End: 0.602 in
- Dim. D: Bolt Clearance: 0.283 in
- Dim. E: Wrench Depth: 0.551 in
- Weight (Catalog): 0.11 lbs.
- Size: 10mm
- Socket Size (mm): 10mm
13mm Standard Socket:
- Dim. A: Drive End: 0.866 in
- Dim. B: Wrench End: 0.748 in
- Dim. D: Bolt Clearance: 0.421 in
- Dim. E: Wrench Depth: 0.551 in
- Weight (Catalog): 0.12 lbs.
- Size: 13mm
- Socket Size (mm): 13mm
14mm Standard Socket:
- Dim. A: Drive End: 0.866 in
- Dim. B: Wrench End: 0.799 in
- Dim. D: Bolt Clearance: 0.421 in
- Dim. E: Wrench Depth: 0.571 in
- Weight (Catalog): 0.12 lbs.
- Size: 14mm
- Socket Size (mm): 14mm
15mm Standard Socket:
- Dim. A: Drive End: 0.866 in
- Dim. B: Wrench End: 0.843 in
- Dim. D: Bolt Clearance: 0.421 in
- Dim. E: Wrench Depth: 0.571 in
- Weight (Catalog): 0.12 lbs.
- Size: 15mm
- Socket Size (mm): 15mm
16mm Standard Socket:
- Dim. A: Drive End: 0.866 in
- Dim. B: Wrench End: 0.850 in
- Dim. D: Bolt Clearance: 0.472 in
- Dim. E: Wrench Depth: 0.571 in
- Weight (Catalog): 0.13 lbs.
- Size: 16mm
- Socket Size (mm): 16mm
17mm Standard Socket:
- Dim. A: Drive End: 0.941 in
- Dim. B: Wrench End: 0.941 in
- Dim. D: Bolt Clearance: 0.472 in
- Dim. E: Wrench Depth: 0.591 in
- Weight (Catalog): 0.15 lbs.
- Size: 17mm
- Socket Size (mm): 17mm
18mm Standard Socket:
- Dim. A: Drive End: 0.980 in
- Dim. B: Wrench End: 0.980 in
- Dim. D: Bolt Clearance: 0.472 in
- Dim. E: Wrench Depth: 0.591 in
- Weight (Catalog): 0.17 lbs.
- Size: 18mm
- Socket Size (mm): 18mm
19mm Standard Socket:
- Dim. A: Drive End: 1.020 in
- Dim. B: Wrench End: 1.020 in
- Dim. D: Bolt Clearance: 0.472 in
- Dim. E: Wrench Depth: 0.768 in
- Weight (Catalog): 0.18 lbs.
- Size: 19mm
- Socket Size (SAE): 19mm
20mm Standard Socket:
- Dim. A: Drive End: 1.094 in
- Dim. B: Wrench End: 1.094 in
- Dim. D: Bolt Clearance: 0.472 in
- Dim. E: Wrench Depth: 0.768 in
- Weight (Catalog): 0.18 lbs.
- Size: 20mm
- Socket Size (SAE): 20mm
21mm Standard Socket:
- Dim. A: Drive End: 1.098 in
- Dim. B: Wrench End: 1.098 in
- Dim. D: Bolt Clearance: 0.472 in
- Dim. E: Wrench Depth: 0.768 in
- Weight (Catalog): 0.18 lbs.
- Size: 21mm
- Socket Size (SAE): 21mm
22mm Standard Socket:
- Dim. A: Drive End: 1.177 in
- Dim. B: Wrench End: 1.177 in
- Dim. D: Bolt Clearance: 0.472 in
- Dim. E: Wrench Depth: 0.768 in
- Weight (Catalog): 0.22 lbs.
- Size: 22mm
- Socket Size (SAE): 22mm
24mm Standard Socket:
- Dim. A: Drive End: 1.256 in
- Dim. B: Wrench End: 1.256 in
- Dim. D: Bolt Clearance: 0.472 in
- Dim. E: Wrench Depth: 0.807 in
- Weight (Catalog): 0.28 lbs.
- Size: 24mm
- Socket Size (SAE): 24mm
