Features
- Memory Stores 10 Results - Store up to 10 measurements or results with the Memory function.
- Accurate to ±1,5mm
- Bluetooth Smart (4.0) - Send measurements directly to your apps using Bluetooth Smart.
- Min/ Max Function - In Min/Max mode, you sweep the laser point into a corner. The longest measurement is recorded. Very useful for accurate diagonal room or window/door measurements.
- Area / Volume - In area mode, the DISTO determines the area of a rectangle or square in two shots. Volume mode adds a third vertical shot to calculate volume.
- Painter Function - When the DISTO is in area or volume mode, you can use the add / subtract function to total up the area of several surfaces, or subtract an area, like a door for example, from a measurement.
- Two and Three Point Pythagoras Function - The key is to make sure your second shot -- the rectangular shot -- is perpendicular to the point you are measuring, shown as the 90° angle in the images. The best way to ensure accuracy is to use a tripod and an adapter.
- Stake out function - uses the continuous measurement mode to indicate where to place stakes along a stake-out line. Ideal for any situation where you need to place objects at a consistent interval. The display shows the distance to the next stake out point and the DISTO beeps as you approach it.
- Intelligent End Piece - The end piece is an integral part of the tool, connected to the circuit board. In the closed position the DISTO knows to measure from its base. Flip it open 90 degrees to align the base perfectly on an edge or corner. Flip it out all the way and you can put this baby in a corner to accurately measure diagonals. Otherwise, the width of the base would prevent you from getting all the way into the corner, rendering the measurement inaccurate.
- Add / Subtract - It's not always so simple as taking one shot to get the measurement you need. Sometimes its handy to add multiple shots together, or subtract a negative space from a measurement. As you use the Add/Subtract function, the final result is displayed in the main line, and the last measurement taken is shown above.
- Timer - Set a timer to delay a measurement the same way you would with the shutter on a digital camera.
Specifications
- Typical measuring accuracy ±1.5 mm
- ISO 16331-1 certified Range up to 100 m
- Measuring units 0.000 m, 0.00 ft, 0ft 00in 1/16, 0 in 1/16
- Memory Last 10 values
- Data Interface Bluetooth Smart V4.0
- Measurements per set of batteries up to 10000
- Multifunctional end-piece Yes, intelligent recognition
- Batteries 2x AAA 1.5 V (Ships with alkaline)
- Display 3 line display with illumination
- Protection class IP 54, dust & water protected
- Dimensions 116 x 44 x 26 mm
- Weight with batteries 100 g / 3.53 oz
- Minimum / maximum measurements Yes
- Area / volume calculation Yes
- Pythagoras functions 2 points, 3 points
- Stake-out function Yes, single value
- Painter function Yes
- Subtraction / addition Yes
- Timer function Yes, variable
- Beep Yes, switchable on/off
- Operating temperature range -10°C to 50°C
- Storage temperature range -25°C to 70°C
- EAN/UPC 7640110696354 (US, CAN)
