Gearwrench offers a wide range of impact products in open stock & sets that are designed to deliver the performance and strength that the professional users require. They are made from chrome molybdenum alloy steel for exceptional strength and durability. Gearwrench's sockets have a manganese phosphate coating to resist corrosion. The sockets also feature highly visible laser etched markings and a secondary size hard stamping. The sockets feature off-corner loading to reduce fastener rounding. The Gearwrench impact product family will allow the professional user to forge ahead.
Features:
- Chrome molybdenum alloy steel (Cr-Mo) for exceptional strength and durability
- Off-corner loading design reduces fastener rounding
- Black oxide finish to resist corrosion
- High-visibility laser-etched markings provide quick size identification
- Secondary hard stamped size markings
- Meets or exceeds ASME specifications
- Prop 65: No Warning
Specifications:
- ASME Specification: B107.33M
- Type: Socket
- Packaging: Hang Tab
- Warranty: Full Lifetime
- Drive Tang Size: 1/2 in
- Length Format: Standard
- Finish: Black Oxide
- Magnetic: No
- SAE/Metric/Torx: Metric
- Drive Type: 6 Point
- Material: Chrome-Molybdenum (Cr-Mo)
8mm Standard Impact Metric Socket:
- Dim. A: Drive End: 0.913 in
- Dim. B: Wrench End: 0.591 in
- Dim. D: Bolt Clearance: 0.236 in
- Dim. E: Wrench Depth: 0.276 in
- Dim. F: Length to Shoulder: 0.748 in
- Size: 8mm
- Overall Length: 1.496 in
- Weight (Catalog): 0.13 lbs.
- Socket Size (mm): 8mm
9mm Standard Impact Metric Socket:
- Dim. A: Drive End: 0.913 in
- Dim. B: Wrench End: 0.63 in
- Dim. D: Bolt Clearance: 0.276 in
- Dim. E: Wrench Depth: 0.315 in
- Dim. F: Length to Shoulder: 0.748 in
- Size: 9mm
- Overall Length: 1.496 in
- Weight (Catalog): 0.13 lbs.
- Socket Size (mm): 9mm
10mm Standard Impact Metric Socket:
- Dim. A: Drive End: 0.976 in
- Dim. B: Wrench End: 0.689 in
- Dim. D: Bolt Clearance: 0.315 in
- Dim. E: Wrench Depth: 0.315 in
- Dim. F: Length to Shoulder: 0.748 in
- Size: 10mm
- Overall Length: 1.496 in
- Weight (Catalog): 0.16 lbs.
- Socket Size (mm): 10mm
11mm Standard Impact Metric Socket:
- Dim. A: Drive End: 0.976 in
- Dim. B: Wrench End: 0.728 in
- Dim. D: Bolt Clearance: 0.394 in
- Dim. E: Wrench Depth: 0.315 in
- Dim. F: Length to Shoulder: 0.748 in
- Size: 11mm
- Overall Length: 1.496 in
- Weight (Catalog): 0.16 lbs.
- Socket Size (mm): 11mm
12mm Standard Impact Metric Socket:
- Dim. A: Drive End: 0.976 in
- Dim. B: Wrench End: 0.768 in
- Dim. D: Bolt Clearance: 0.394 in
- Dim. E: Wrench Depth: 0.354 in
- Dim. F: Length to Shoulder: 0.748 in
- Size: 12mm
- Overall Length: 1.496 in
- Weight (Catalog): 0.16 lbs.
- Socket Size (mm): 12mm
13mm Standard Impact Metric Socket:
- Dim. A: Drive End: 0.976 in
- Dim. B: Wrench End: 0.819 in
- Dim. D: Bolt Clearance: 0.394 in
- Dim. E: Wrench Depth: 0.394 in
- Dim. F: Length to Shoulder: 0.748 in
- Size: 13mm
- Overall Length: 1.496 in
- Weight (Catalog): 0.17 lbs.
- Socket Size (mm): 13mm
14mm Standard Impact Metric Socket:
- Dim. A: Drive End: 0.976 in
- Dim. B: Wrench End: 0.866 in
- Dim. D: Bolt Clearance: 0.472 in
- Dim. E: Wrench Depth: 0.394 in
- Dim. F: Length to Shoulder: 0.748 in
- Size: 14mm
- Overall Length: 1.496 in
- Weight (Catalog): 0.18 lbs.
- Socket Size (mm): 14mm
15mm Standard Impact Metric Socket:
- Dim. A: Drive End: 0.976 in
- Dim. B: Wrench End: 0.976 in
- Dim. D: Bolt Clearance: 0.472 in
- Dim. E: Wrench Depth: 0.433 in
- Dim. F: Length to Shoulder: 1.496 in
- Size: 15mm
- Overall Length: 1.496 in
- Weight (Catalog): 0.20 lbs.
- Socket Size (mm): 15mm
16mm Standard Impact Metric Socket:
- Dim. A: Drive End: 0.976 in
- Dim. B: Wrench End: 0.976 in
- Dim. D: Bolt Clearance: 0.472 in
- Dim. E: Wrench Depth: 0.433 in
- Dim. F: Length to Shoulder: 1.496 in
- Size: 16mm
- Overall Length: 1.496 in
- Weight (Catalog): 0.19 lbs.
- Socket Size (mm): 16mm
17mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.016 in
- Dim. B: Wrench End: 1.016 in
- Dim. D: Bolt Clearance: 0.472 in
- Dim. E: Wrench Depth: 0.472 in
- Dim. F: Length to Shoulder: 1.496 in
- Size: 17mm
- Overall Length: 1.496 in
- Weight (Catalog): 0.21 lbs.
- Socket Size (mm): 17mm
18mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.094 in
- Dim. B: Wrench End: 1.094 in
- Dim. D: Bolt Clearance: 0.571 in
- Dim. E: Wrench Depth: 0.512 in
- Dim. F: Length to Shoulder: 1.496 in
- Size: 18mm
- Overall Length: 1.496 in
- Weight (Catalog): 0.25 lbs.
- Socket Size (mm): 18mm
19mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.173 in
- Dim. B: Wrench End: 1.173 in
- Dim. D: Bolt Clearance: 0.571 in
- Dim. E: Wrench Depth: 0.512 in
- Dim. F: Length to Shoulder: 1.614 in
- Size: 19mm
- Overall Length: 1.614 in
- Weight (Catalog): 0.33 lbs.
- Socket Size (mm): 19mm
20mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.173 in
- Dim. B: Wrench End: 1.173 in
- Dim. D: Bolt Clearance: 0.61 in
- Dim. E: Wrench Depth: 0.512 in
- Dim. F: Length to Shoulder: 1.614 in
- Size: 20mm
- Overall Length: 1.614 in
- Weight (Catalog): 0.32 lbs.
- Socket Size (mm): 20mm
21mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.252 in
- Dim. B: Wrench End: 1.252 in
- Dim. D: Bolt Clearance: 0.61 in
- Dim. E: Wrench Depth: 0.551 in
- Dim. F: Length to Shoulder: 1.614 in
- Size: 21mm
- Overall Length: 1.614 in
- Weight (Catalog): 0.38 lbs.
- Socket Size (mm): 21mm
22mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.252 in
- Dim. B: Wrench End: 1.252 in
- Dim. D: Bolt Clearance: 0.669 in
- Dim. E: Wrench Depth: 0.551 in
- Dim. F: Length to Shoulder: 1.614 in
- Size: 22mm
- Overall Length: 1.614 in
- Weight (Catalog): 0.37 lbs.
- Socket Size (mm): 22mm
23mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.331 in
- Dim. B: Wrench End: 1.331 in
- Dim. D: Bolt Clearance: 0.669 in
- Dim. E: Wrench Depth: 0.551 in
- Dim. F: Length to Shoulder: 1.614 in
- Size: 23mm
- Overall Length: 1.614 in
- Weight (Catalog): 0.41 lbs.
- Socket Size (mm): 23mm
24mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.331 in
- Dim. B: Wrench End: 1.331 in
- Dim. D: Bolt Clearance: 0.669 in
- Dim. E: Wrench Depth: 0.551 in
- Dim. F: Length to Shoulder: 1.614 in
- Size: 24mm
- Overall Length: 1.614 in
- Weight (Catalog): 0.40 lbs.
- Socket Size (mm): 24mm
25mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.409 in
- Dim. B: Wrench End: 1.409 in
- Dim. D: Bolt Clearance: 0.709 in
- Dim. E: Wrench Depth: 0.551 in
- Dim. F: Length to Shoulder: 1.614 in
- Size: 25mm
- Weight (Catalog): 0.47 lbs.
- Socket Size (mm): 25mm
26mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.488 in
- Dim. B: Wrench End: 1.488 in
- Dim. D: Bolt Clearance: 0.866 in
- Dim. E: Wrench Depth: 0.591 in
- Dim. F: Length to Shoulder: 1.614 in
- Size: 26mm
- Overall Length: 1.614 in
- Weight (Catalog): 0.53 lbs.
- Socket Size (mm): 26mm
27mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.488 in
- Dim. B: Wrench End: 1.488 in
- Dim. D: Bolt Clearance: 0.906 in
- Dim. E: Wrench Depth: 0.63 in
- Dim. F: Length to Shoulder: 1.614 in
- Size: 27mm
- Overall Length: 1.614 in
- Weight (Catalog): 0.51 lbs.
- Socket Size (mm): 27mm
28mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.606 in
- Dim. B: Wrench End: 1.606 in
- Dim. D: Bolt Clearance: 0.945 in
- Dim. E: Wrench Depth: 0.63 in
- Dim. F: Length to Shoulder: 1.614 in
- Size: 28 mm
- Overall Length:1.614 in
- Weight (Catalog): 0.56 lbs.
- Socket Size (mm): 28mm
30mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.646 in
- Dim. B: Wrench End: 1.646 in
- Dim. D: Bolt Clearance: 0.984 in
- Dim. E: Wrench Depth: 0.661 in
- Dim. F: Length to Shoulder: 1.614 in
- Size: 30mm
- Overall Length:1.614 in
- Weight (Catalog): 0.63 lbs.
- Socket Size (mm): 30mm
32mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.724 in
- Dim. B: Wrench End: 1.724 in
- Dim. D: Bolt Clearance: 1.024 in
- Dim. E: Wrench Depth: 0.638 in
- Dim. F: Length to Shoulder: 1.614 in
- Size: 32mm
- Overall Length:1.614 in
- Weight (Catalog): 0.69 lbs.
- Socket Size (mm): 32mm
36mm Standard Impact Metric Socket:
- Dim. A: Drive End: 1.921 in
- Dim. B: Wrench End: 1.921 in
- Dim. D: Bolt Clearance: 1.023 in
- Dim. E: Wrench Depth: 1.063 in
- Dim. F: Length to Shoulder: 1.909 in
- Size: 36mm
- Overall Length:1.909 in
- Weight (Catalog): 0.90 lbs.
- Socket Size (mm): 36mm
