Features:
- High-leverage joint, long handles and optimized cutting edges for an easier cut than with compact cable shears
- Cuts solid copper or aluminum cables up to 2 AWG, stranded cables up to 2/0 AWG and fine stranded cables up to 4/0 AWG
- Dual cutting areas: step cutting edges position cables close to the joint and the front cutting edge is used for the gradual cutting ("nibbling") of larger cables
- Easy one- or two-handed operation with minimal handle opening for large cable diameters
- Slim head for better accessibility
- Not suitable for steel-reinforced cables, e.g. ACSR
- Adjustable, high-leverage bolted joint provides precise and smooth cutting
- Pinch guard prevents operators' fingers being pinched
- Laser-hardened cutting edges (approx. 56 HRC)
- High-grade special tool steel; forged; oil-hardened
Technical Details:
- Part Number: 95 11 225
- UPC: 843221029722
- Country of Origin: Germany
- Length: 9"
- Width: 1 3/4"
- Height: 5/8"
- Weight: 0.806 lbs.
- 1000 Volt Insulated: No
- ESD Indicator: No
- Spring Loaded: No
- Material Type: High-grade special tool steel, forged, oil-hardened
- Handle Type: Plastic coating
- Surface Finish: Burnished
- Joint Type: Bolted
- Cutting Capacity - Cu and Al conductor: 29/32"
- Cutting Edge Shape: Shear
- Jaw Length: 1 1/4"
- Jaw Width: 1 1/4"
- Jaw Thickness: 1/2"
- Tip Thickness: 1/4"
- Tip Width: 1"
- Wire Size: Up to 2/0 AWG (solid and stranded cables), Up to 4/0 AWG (fine stranded cables)
- Cable Type: Stranded Cables | Fine Stranded Cables | Solid Cable
- Reach: does not contain SVHC
- RoHS: not applicable
Warnings:
- Do no use on live circuits. Always switch off power.
- Warning: Always wear approved eye protection.
