GEARWRENCH offers a wide range of impact products in open stock & sets that are designed to deliver the performance and strength that the professional users require. They are made from chrome molybdenum alloy steel for exceptional strength and durability. Gearwrench's sockets have a manganese phosphate coating to resist corrosion. The sockets also feature highly visible laser etched markings and a secondary size hard stamping. The sockets feature off-corner loading to reduce fastener rounding. The GEARWRENCH impact product family will allow the professional user to Forge Ahead.
Features:
- Chrome molybdenum alloy steel (Cr-Mo) for exceptional strength and durability
- Off-corner loading design reduces fastener rounding
- Manganese phosphate finish to resist corrosion
- High-visibility laser-etched markings provide quick size identification
- Secondary hard stamped size markings
- Meets or exceeds ASME specifications
Specifications:
- Dim. A : Drive End : 1.732 in
- Prop 65 :No Warning
- ASME Specification : B107.33M
- Type : Socket
- Packaging : Hang Tab
- Warranty : Full Lifetime
- Drive Tang Size : 3/4 in
- Length Format : Standard
- Finish : Manganese Phosphate
- Magnetic : No
- SAE/Metric/Torx : Metric
- Material : Chrome-Molybdenum (Cr-Mo)
3/4in Drive 6 Point Standard Impact Metric Socket 30mm:
- Dim. B : Wrench End : 1.811 in
- Dim. D : Bolt Clearance : 0.787 in
- Dim. E : Wrench Depth : 0.655 in
- Dim. F : Length to Shoulder : 2.086 in
- Overall Length : 2.087 in
- Size : 30mm
- Weight (Catalog) : 0.92 lbs.
- Socket Size (mm) : 30mm
3/4in Drive 6 Point Standard Impact Metric Socket 31mm:
- Dim. B : Wrench End : 1.89 in
- Dim. D : Bolt Clearance : 0.866 in
- Dim. E : Wrench Depth : 0.7 in
- Dim. F : Length to Shoulder : 2.244 in
- Overall Length : 2.205 in
- Size : 31mm
- Weight (Catalog) : 1.03 lbs.
- Socket Size (mm) : 31mm
3/4in Drive 6 Point Standard Impact Metric Socket 32mm:
- Dim. B : Wrench End : 1.89 in
- Dim. D : Bolt Clearance : 0.905 in
- Dim. E : Wrench Depth : 0.72 in
- Dim. F : Length to Shoulder : 2.244 in
- Overall Length : 2.205 in
- Size : 32mm
- Weight (Catalog) : 1.02 lbs.
- Socket Size (mm) : 32mm
3/4in Drive 6 Point Standard Impact Metric Socket 34mm:
- Dim. B : Wrench End : 2.008 in
- Dim. D : Bolt Clearance : 0.944 in
- Dim. E : Wrench Depth : 0.787 in
- Dim. F : Length to Shoulder : 2.244 in
- Overall Length : 2.205 in
- Size : 34mm
- Weight (Catalog) : 1.09 lbs.
- Socket Size (mm) : 34mm
3/4in Drive 6 Point Standard Impact Metric Socket 35mm:
- Dim. B : Wrench End : 2.047 in
- Dim. D : Bolt Clearance : 0.944 in
- Dim. E : Wrench Depth : 0.791 in
- Dim. F : Length to Shoulder : 2.244 in
- Overall Length : 2.205 in
- Size : 35mm
- Weight (Catalog) : 1.12 lbs.
- Socket Size (mm) : 35mm
3/4in Drive 6 Point Standard Impact Metric Socket 36mm:
- Dim. B : Wrench End : 2.087 in
- Dim. D : Bolt Clearance : 1.023 in
- Dim. E : Wrench Depth : 0.844 in
- Dim. F : Length to Shoulder : 2.244 in
- Overall Length : 2.205 in
- Size : 36mm
- Weight (Catalog) : 1.14 lbs.
- Socket Size (mm) : 36mm
3/4in Drive 6 Point Standard Impact Metric Socket 37mm:
- Dim. B : Wrench End : 2.165 in
- Dim. D : Bolt Clearance : 1.023 in
- Dim. E : Wrench Depth : 0.844 in
- Dim. F : Length to Shoulder : 2.244 in
- Overall Length : 2.205 in
- Size : 37mm
- Weight (Catalog) : 1.16 lbs.
- Socket Size (mm) : 37mm
3/4in Drive 6 Point Standard Impact Metric Socket 38mm:
- Dim. B : Wrench End : 2.205 in
- Dim. D : Bolt Clearance : 1.062 in
- Dim. E : Wrench Depth : 0.875 in
- Dim. F : Length to Shoulder : 2.244 in
- Overall Length : 2.205 in
- Size : 38mm
- Weight (Catalog) : 1.17 lbs.
- Socket Size (mm) : 38mm
3/4in Drive 6 Point Standard Impact Metric Socket 46mm:
- Dim. B : Wrench End : 2.598 in
- Dim. D : Bolt Clearance : 1.279 in
- Dim. E : Wrench Depth : 1.125 in
- Dim. F : Length to Shoulder : 2.44 in
- Overall Length : 2.441 in
- Size : 46mm
- Weight (Catalog) : 1.54 lbs.
- Socket Size (mm) : 46mm
