GEARWRENCH GW-8037X 3/8in Drive 6 Point Standard Metric Socket

Gearwrench 3/8" drive sockets are manufactured from alloy steel for maximum durability and strength. Gearwrench's off corner loading design reduces fastener rounding and the chamfered opening help guide the socket on to fasteners. Gearwrench's sockets feature a double line (SAE) and knurled (metric) ring help easily identify standard and metric sockets.

Features:

• Off-corner loading design reduces fastener rounding
• Chamfered opening quickly guides fasteners into socket
• Hard stamped size markings
• Double line (SAE) and knurled (metric) ring help easily identify standard and metric sockets
• Bright, full polish chrome finish easily wipes clean and resists corrosion
• Meets or exceeds ASME specifications

• Prop 65: WARNING: This product contains or produces a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.

Specifications:

• ASME Specification: B107.5M
• Drive Tang Size: 3/8 in
• Knurled: Yes
• ANSI Specification: Meets or Exceeds
• Type: Socket
• Warranty: Full Lifetime
• Length Format: Standard
• Finish: Full Polish Chrome
• Magnetic: No
• SAE/Metric/Torx: Metric
• Drive Type: 6 Point
• Material: Alloy Steel
• Dim. F : Length to Shoulder : 0.453 in

6mm Standard Socket:

• Dim. A : Drive End : 0.669 in
• Dim. B : Wrench End : 0.366 in
• Dim. D : Bolt Clearance : 0.197 in
• Dim. E : Wrench Depth : 0.295 in
• Overall Length: 0.984 in
• Weight: 0.04 lbs.
• Socket Size (mm) : 6mm
• Size: 6mm

7mm Standard Socket:

• Dim. A : Drive End : 0.669 in
• Dim. B : Wrench End : 0.425 in
• Dim. D : Bolt Clearance : 0.197 in
• Dim. E : Wrench Depth : 0.295 in
• Overall Length: 0.984 in
• Weight: 0.03 lbs.
• Socket Size (mm) : 7mm
• Size: 7mm

8mm Standard Socket:

• Dim. A : Drive End : 0.669 in
• Dim. B : Wrench End : 0.472 in
• Dim. D : Bolt Clearance : 0.283 in
• Dim. E : Wrench Depth : 0.295 in
• Overall Length: 0.984 in
• Weight: 0.03 lbs.
• Socket Size (mm) : 8mm
• Size: 8mm

9mm Standard Socket:

• Dim. A : Drive End : 0.669 in
• Dim. B : Wrench End : 0.508 in
• Dim. D : Bolt Clearance : 0.283 in
• Dim. E : Wrench Depth : 0.295 in
• Overall Length: 0.984 in
• Weight: 0.04 lbs.
• Socket Size (mm) : 9mm
• Size: 9mm

10mm Standard Socket:

• Dim. A : Drive End : 0.669 in
• Dim. B : Wrench End : 0.571 in
• Dim. D : Bolt Clearance : 0.283 in
• Dim. E : Wrench Depth : 0.295 in
• Overall Length: 0.984 in
• Weight: 0.04 lbs.
• Socket Size (mm) : 10mm
• Size: 10mm

11mm Standard Socket:

• Dim. A : Drive End : 0.669 in
• Dim. B : Wrench End : 0.622 in
• Dim. D : Bolt Clearance : 0.354 in
• Dim. E : Wrench Depth : 0.295 in
• Overall Length: 0.984 in
• Weight: 0.03 lbs.
• Socket Size (mm) : 11mm
• Size: 11mm

12mm Standard Socket:

• Dim. A : Drive End : 0.669 in
• Dim. B : Wrench End : 0.654 in
• Dim. D : Bolt Clearance : 0.354 in
• Dim. E : Wrench Depth : 0.315 in
• Overall Length: 0.984 in
• Weight: 0.03 lbs.
• Socket Size (mm) : 12mm
• Size: 12mm

13mm Standard Socket:

• Dim. A : Drive End : 0.72 in
• Dim. B : Wrench End : 0.697 in
• Dim. D : Bolt Clearance : 0.354 in
• Dim. E : Wrench Depth : 0.315 in
• Overall Length: 0.984 in
• Weight: 0.06 lbs.
• Socket Size (mm) : 13mm
• Size: 13mm

14mm Standard Socket:

• Dim. A : Drive End : 0.768 in
• Dim. B : Wrench End : 0.768 in
• Dim. D : Bolt Clearance : 0.354 in
• Dim. E : Wrench Depth : 0.492 in
• Overall Length: 0.984 in
• Weight: 0.06 lbs.
• Socket Size (mm) : 14mm
• Size: 14mm

15mm Standard Socket:

• Dim. A : Drive End : 0.819 in
• Dim. B : Wrench End : 0.819 in
• Dim. D : Bolt Clearance : 0.354 in
• Dim. E : Wrench Depth : 0.492 in
• Overall Length: 0.984 in
• Weight: 0.07 lbs.
• Socket Size (mm) : 15mm
• Size: 15mm

16mm Standard Socket:

• Dim. A : Drive End : 0.866 in
• Dim. B : Wrench End : 0.866 in
• Dim. D : Bolt Clearance : 0.354 in
• Dim. E : Wrench Depth : 0.492 in
• Overall Length: 0.984 in
• Weight: 0.08 lbs.
• Socket Size (mm) : 16mm
• Size: 16mm

17mm Standard Socket:

• Dim. A : Drive End : 0.917 in
• Dim. B : Wrench End : 0.917 in
• Dim. D : Bolt Clearance : 0.354 in
• Dim. E : Wrench Depth : 0.492 in
• Overall Length: 0.984 in
• Weight: 0.11 lbs.
• Socket Size (mm) : 17mm
• Size: 17mm

18mm Standard Socket:

• Dim. A : Drive End : 0.937 in
• Dim. B : Wrench End : 0.937 in
• Dim. D : Bolt Clearance : 0.354 in
• Dim. E : Wrench Depth : 0.492 in
• Overall Length: 0.984 in
• Weight: 0.11 lbs.
• Socket Size (mm) : 18mm
• Size: 18mm

19mm Standard Socket:

• Dim. A : Drive End : 0.937 in
• Dim. B : Wrench End : 0.937 in
• Dim. D : Bolt Clearance : 0.354 in
• Dim. E : Wrench Depth : 0.492 in
• Overall Length: 0.984 in
• Weight: 0.13 lbs.
• Socket Size (mm) : 19mm
• Size: 19mm

20mm Standard Socket:

• Dim. A : Drive End : 1.051 in
• Dim. B : Wrench End : 1.098 in
• Dim. D : Bolt Clearance : 0.354 in
• Dim. E : Wrench Depth : 0.591 in
• Overall Length: 1.102 in
• Weight: 0.19 lbs.
• Socket Size (mm) : 20mm
• Size: 20mm
